Engineered air and gas handling for hydrocarbon vapors, methane gas mitigation, brownfield remediation, oil spill response, and other demanding petrochemical applications
Tell us about your process and we'll follow up with a recommendation.
Application brief
Petrochemical operations put unusual demands on a blower. The gas itself might be corrosive, hazardous, or running at temperatures most equipment isn't built for. The application might not even be in a plant at all, but on a ship, responding to an oil spill where the blower has to run on hydraulic power because there is no reliable electrical supply on hand. Sonic Air Systems engineers design around both realities, analyzing each plant's specific conditions and variables to integrate the right blower into the environment it actually has to operate in.
That range shows up in what Sonic has already built for this industry: patented heater-less hot air drying systems for petrochemical-adjacent fluid handling, and hydraulic-driven marine duty blowers that have spent over two decades responding to oil spills at sea.
Process requirements
Sonic's patented Dry-In-Place (heater-less) hot air blower system dries up to eight 55-gallon barrels in 20 minutes per batch, and pairs of 264-gallon IBC totes in 45 minutes, at 160°F outlet air temperature without a secondary heat source.
Sonic blowers handle gas compositions at temperatures up to 400°F, supporting hydrocarbon vapor, digester gas, and other hazardous gas handling needs.
Over 100 Sonic hydraulic-driven marine duty blowers, generating 3 psig to rapidly inflate oil containment booms, have been deployed across Marine Spill Response Corporation's fleet for over 33 years, including during the 2010 B.P. oil spill response in the Gulf of Mexico.
Because Sonic's marine duty blowers run on hydraulic power, they operate independent of shipboard electrical systems, which matters when the equipment has to work reliably in an emergency response setting.
Sonic blowers deliver brownfield remediation and soil vapor extraction solutions at residential and commercial sites to meet EPA regulatory requirements.
Engineering detail
System requirements
Some petrochemical-adjacent processes depend on a completely water-free environment before a fluid ever goes into its container. Transformer manufacturing is a good example: barrels and plastic IBC totes have to be thoroughly dried after CIP washing and before they're filled with degassed, dehumidified oil, since any residual moisture puts the transformer at risk of corrosion. Traditional hot air drying methods can turn that step into a bottleneck, stretching drying times and eating up warehouse space waiting for totes and barrels to be ready. Sonic's patented Dry-In-Place Tank Dryer, a heater-less hot air blower system, dries up to eight 55-gallon barrels simultaneously in 20 minutes per batch, and pairs of 264-gallon totes in 45 minutes, despite the added challenge totes present from water surface tension and structural limitations. The system reaches a 160°F outlet air temperature without relying on a secondary heat source, keeping energy use and complexity down while still hitting complete dryness.
Engineering detail
Oil spill response equipment has to work the first time, every time, often in conditions where shore power or a reliable electrical supply isn't an option. Sonic's hydraulic-driven blowers were built for exactly that constraint, generating 3 psig to inflate a continuous spool of 125 ft³ oil containment booms every 20 seconds using hydraulic power rather than an electric motor. That combination of reliability and independence from shipboard power is why these blowers have remained standard equipment on response vessels for over 25 years, including deployment during the 2010 B.P. oil spill cleanup in the Gulf of Mexico, one of the largest marine oil spill responses on record.
System requirements
Methane gas in soil can occur naturally, from ancient buried organic material, wetlands, or glacial and silty soil formations, or it can result from human activity: old landfill deposits, engineered fill, leaking storage tanks, or past industrial and chemical spills. The EPA regulates soil and vapor intrusion exposure to protect nearby workers, residents, and the environment, which puts real compliance pressure on any site being redeveloped or actively monitored.
Sonic works alongside environmental engineering firms to supply the blower systems behind soil vapor mitigation designs, ranging from passive soil gas extraction and venting to air dike and barrier membrane systems that keep methane from migrating into occupied structures. Explosion-proof configurations are available for sites where the vapor itself is a combustion risk. System sizing runs from a single blower on one extraction point up to multi-blower setups with integrated monitoring controls, matched to the site's soil conditions and the regulatory standard it has to meet.
Production proof
Koncar D&ST, a leading producer and distributor of medium-power electrical and special transformers, needed barrels and plastic IBC totes completely dry after CIP washing and before filling with degassed, dehumidified oil, since any residual moisture put the transformers at risk of corrosion. Their existing hot air drying methods meant extended drying times, more warehouse space tied up waiting on dry containers, and added production cost. Sonic, through its UK office, installed a patented heater-less Dry-In-Place hot air blower system that dries up to eight 55-gallon barrels simultaneously in 20 minutes per batch, and pairs of 264-gallon totes in 45 minutes, at a 160°F outlet air temperature with no secondary heat source. The result was faster drying, freed-up warehouse space, and lower energy consumption and cost than Koncar’s previous method. Full details are in Sonic’s published case study, Cost Saving Solution with Sonic’s Dry-In-Place Tank Drying System for Transformer Barrel and Tote Drying.
Marine Spill Response Corporation (MSRC) was established in response to the 1989 Exxon Valdez oil spill, with a mission to protect the U.S. coastline, and needed a partner to supply essential equipment for oil spill emergencies. Sonic developed hydraulic-driven air blowers for MSRC’s ships, generating 3 psig to rapidly inflate oil containment booms without depending on shipboard electrical power. Over 100 of these robust, lightweight blowers have been deployed across MSRC’s fleet, proving reliable for over 33 years, including during the massive cleanup effort following the 2010 B.P. oil spill in the Gulf of Mexico. Full details are in Sonic’s published case study, Rapid Oil Spill Response at Sea with Sonic Air Systems’ Hydraulic-Driven Air Blower Technology.
Universal Studios Hollywood needed a way to safely extract methane gas for the backdraft effects used in one of its attractions, keeping the gas properly vented and vapor intrusion within EPA-regulated limits, both for guest and worker safety and to pass the site’s ongoing regulatory inspections. Sonic supplied a 20 HP Sonic Air Blower System engineered for that specific extraction task, part of a broader methane gas and vapor intrusion remediation program Sonic has supported for the past 25 years across sites that include residential developments and industrial salvage yards alongside the theme park. The system runs continuously without downtime, housed in a stainless steel enclosure that keeps noise under 80 dBA to meet OSHA’s standard.
Talk through the application
Tell us the gas composition, temperature range, and operating environment, on-site or mobile, and we will help size the right system.
